The device is especially aimed at organic solvents, and the inert gas medium formed by circulating nitrogen gas is used to replace the usual air medium for spray drying. In addition to recovering products, organic solvents can also be recovered. This set of closed circulation spray system is specially designed for organic solvents with low flash point or slightly toxic characteristics, flammable and explosive characteristics.
1. Can prevent oxidation, avoid danger and improve quality.
2. Easy to achieve aseptic and dust-free.
3. The solvent in the feed liquid can be recovered.
4. Improve the preservation of aromatic components.
5. It can dry or cool and granulate combustible material liquid.
6. It can dry the material liquid with high heat sensitivity.
7. It can achieve low pollution and no pollution.
8. The deodorizing device can be omitted.
9. It can be dried at a low temperature below 100°C.
10. Using an innovative atomization system, this system uses a hard contact mechanical structure without any gaskets and no leakage. Different from ordinary electric centrifugal nozzles, the superheated corrosive steam contacts the wires of the electric nozzle for a long time under positive pressure, thereby corroding the wires, causing the plastic skin on the surface of the wires to corrode, soften and fall off, thus forming a short circuit. Ultrafine powder in the range of 1-8 microns can be achieved, which is suitable for the preparation of battery materials.
Model | LBL-DP1 | LBL-DP3 | LBL-DP5 |
Ethanol evaporation | 0.8Kg/h | 3Kg/h | 5Kg/h |
Minimum feed amount | 50ml | 80ml | 100ml |
atomization structure | Atomization system (NZY1VER2018-1A) | Atomization system (NZY1VER2018-1A) | Atomization system (NZY1VER2018-1A) |
Electronic control system | LABOAO closed loop atomization system (BLD-ES-VER2018-1A) | LABOAO closed loop atomization system (BLD-ES-VER2018-1A) | LABOAO closed loop atomization system (BLD-ES-VER2018-1A) |
Inlet air temperature (Celsius) | 140 | 140 | 140 |
Drying chamber diameter (mm) | ￠300 | ￠800 | ￠1200 |
Drying tower height (mm) | ￠600 | ￠1200 | ￠1500 |
Explosion-proof disk diameter (mm) | 65 | 65 | 108 |
heater capacity | 2Kw | 6Kw | 12Kw |
Induced fan [power (kw), air volume (m³/h)] | [1.5, 250] | [2.2, 300] | [2.2, 300] |
Compressor [power (kw), air volume (L / min)] | [0.58, 108] | [0.58, 108] | [0.58, 108] |
Chiller | 50-60Hz (built-in cryogenic cooling circulation pump) | 50-60Hz (built-in cryogenic cooling circulation pump) | 50-60Hz (built-in cryogenic cooling circulation pump) |
Electronic control main accessories standard (including PLC, analog module, touch screen) (optional) | Wecon control module (standard) | Wecon control module (standard) | Wecon control module (standard) |
Selection criteria for electric control auxiliary accessories (including contactors, etc.) (optional) | Chint (Standard) | Chint (Standard) | Chint (Standard) |
Parts in contact with the material (optional) | SUS304 (standard) | SUS304 (standard) | SUS304 (standard) |
Exhaust gas reuse, saving energy by more than 30% (optional) | Not assembled (standard) | Not assembled (standard) | Not assembled (standard) |
Atomizing nozzle (optional, diamond coating or not) | SUS304 (standard) | SUS304 (standard) | SUS304 (standard) |
Equipment Warranty | 1 year (standard, a certain maintenance fee will be charged for the above) | 1 year (standard, a certain maintenance fee will be charged for the above) | 1 year (standard, a certain maintenance fee will be charged for the above) |
Electricity (installed capacity) | 4Kw | 12Kw | 30Kw |
Pulse bag filter | PTFE coating material, 2pcs | PTFE coating material, 4pcs | PTFE coating material, 8pcs |
Dimensions (mm) (L×W×H) Reference | 1400×1000×1600 | 1800×1200×1800 | 2100×1200×1800 |
Installation weight (reference) | 200Kg | 450Kg | 1000Kg |
Power supply | 380V/-3￠ (Related voltages can be customized according to different national standards) | 380V/-3￠ (Related voltages can be customized according to different national standards) | 380V/-3￠ (Related voltages can be customized according to different national standards) |
Notes | 1: Ethanol evaporation is based on the inlet air temperature of 140°C; 2: If you need equipment with larger evaporation capacity, please inquire online or call our company | 1: Ethanol evaporation is based on the inlet air temperature of 140°C; 2: If you need equipment with larger evaporation capacity, please inquire online or call our company | 1: Ethanol evaporation is based on the inlet air temperature of 140°C; 2: If you need equipment with larger evaporation capacity, please inquire online or call our company |
